Multilayer precision PCB--The manufacturing method of multilayer board is generally made by the inner layer pattern first, and then the single or double-sided substrate is made by printing and etching method, which is included in the specified interlayer, and then heated, pressurized and bonded. As for the subsequent drilling, it is the same as the plating through-hole method of double-sided board.
14-layer Rigid - Flex PCB The rigid-flex board is also called rigid-flex board. With the birth and development of FPC, the new product of rigid-flex circuit board (soft and hard combined board) is gradually being widely used in various occasions.The following is about 14 layer Rigid - Flex PCB related, I hope to help you better understand 14 layer Rigid - Flex PCB.
10-layer R-F775 Rigid-Flex PCB is a new type of printed circuit board that combines the durability of a rigid PCB and the adaptability of a flexible PCB.medical and military equipment, companies in the mainland are also gradually increasing the proportion of rigid-flex boards in total output.
The 6-layer Rigid-Flex PCB has the characteristics of FPC and PCB at the same time. Therefore, it can be used in some products with special requirements, including flexible areas and rigid areas. It is of great help to save the internal space of products, reduce the volume of finished products and improve the performance of products.
The 12-layer AP9222R Rigid-Flex PCB of flexible circuit board and Rigid circuit board is a kind of circuit board with FPC characteristics and PCB characteristics, which is formed by Rigid - Flex PCB together according to relevant process requirements through pressing and other processes.
FPC flexible board is a kind of flexible printed circuit board which is made of polyimide or polyester film with high reliability and excellent flexibility. It has the characteristics of high density, light weight, thin thickness and good bending property.
