High frequency step PCB With the small and diversified development of electronic products, restricted by the space and security, the traditional plane circuit board can not meet the requirements of many fields of electronic products, and more and more step PCB has been gradually developed.
copper paste filled hole PCB: Bai AE3030 copper pulp is a non-conductive DAO copper paste used for the high-density assembly of printed substrate DU plate and the laying of wires.Due to the characteristics of Zhuan "high Thermal conductivity", "bubble-free", "flat" and so on, the copper paste is most suitable for the design of high reliability Pad on Via, stack on Via and Thermal Via. The copper paste is widely used from aerospace satellite, server, cabling machine, LED backlight and so on.
super big size PCB The advantages of large size PCB lie in one-time and integrity, which reduces the confusion and trouble of piecewise connection, but the cost is relatively high.
Large size PCB super big size pcb-oil rig main board:board thickness 4.0mm, 4layer, L1-L2 blind hole, L3-L4 blind hole, 4/4/4/4oz copper, Tg170, single panel size 820*850mm. oil rig main board:board thickness 4.0mm, 4layer, L1-L2 blind hole, L3-L4 blind hole, 4/4/4/4oz copper, Tg170, single panel size 820*850mm.
EM-528K High-speed PCB is almost everywhere in our industry. And, as quoted, we always say that, regardless of the final product or implementation, each PCB is high-speed with its IC technology.
TU-943N High-speed PCB -- the development of electronic technology is changing with each passing day. This change mainly comes from the progress of chip technology. With the wide application of deep submicron technology, semiconductor technology is becoming increasingly physical limit. VLSI has become the mainstream of chip design and application.
