Signal integrity (SI) issues are becoming a growing concern for digital hardware designers. Due to the increased data rate bandwidth in wireless base stations, wireless network controllers, wired network infrastructure, and military avionics systems, the design of circuit boards has become increasingly complex. The following is about NELCO High Frequency PCB related, I hope to help you better understand NELCO High Frequency PCB.
EM-888 7MM Thick PCB--As user applications require more and more board layers, alignment between layers becomes very important. Alignment between layers requires tolerance convergence. As the board size changes, this convergence requirement is more demanding. All layout processes are generated in a controlled temperature and humidity environment. The following is about EM888 7MM Thick PCB related, I hope to help you better understand EM888 7MM Thick PCB.
Tachyon 100G PCB The exposure equipment is in the same environment. The alignment tolerance of the front and back images of the entire area must be maintained at 0.0125mm. The CCD camera is required to complete the front and rear layout alignment. After etching, the four-hole drilling system was used to perforate the inner layer. The perforation passes through the core board, the position accuracy is maintained at 0.025mm, and the repeatability is 0.0125mm. The following is about Tachyon 100G High-speed PCB related, I hope to help you better understand Tachyon 100G High-speed PCB.
In addition to the requirement for uniform thickness of the plating layer for drilling, backplane designers generally have different requirements for the uniformity of copper on the surface of the outer layer. Some designs etch few signal lines on the outer layer. The following is about Megtron6 step PCB related, I hope to help you better understand Megtron6 step PCB.
For general frequency, use FR-4 sheet, but high-frequency materials should be used in the frequency ratio of 1-5G, such as semi-ceramic materials. ROGERS 4350, 4003, 5880, etc. are commonly used ... If the frequency is higher than 5G, it is best to use PTFE material, which is polytetrafluoroethylene. This material has good high-frequency performance, but there are limitations in the processing arts, such as the surface technology that cannot be hot air leveled. The following is about ISOLA FR408 High Frequency PCB related, I hope to help you better understand ISOLA FR408 High Frequency PCB.
The frequency of vehicle millimeter wave radar is mainly divided into 24GHz frequency band and 77GHz frequency band, of which 77GHz frequency band represents the future trend. The reliability of 77G radar board is very important. It is related to the safety of car driving. Among them, the reliability of electroplating is the most important factor affecting its reliability. The following is about Car Collision Avoidance Radar PCB related, I hope to help you better understand Car Collision Avoidance Radar PCB.
