AP8545R Rigid-Flex PCB refers to the combination of soft board and hard board. It is a circuit board formed by combining the thin flexible bottom layer with the rigid bottom layer, and then laminating into a single component. It has the characteristics of bending and folding. Due to the mixed use of various materials and multiple manufacturing steps, the processing time of rigid Flex PCB is longer and the production cost is higher.
In the PCB proofing of electronic consumer, the use of R-F775 PCB not only maximizes the space use and minimizes the weight, but also greatly improves the reliability, thus eliminating many requirements for welded joints and fragile wiring prone to connection problems. The rigid Flex PCB also has high impact resistance and can survive in high stress environment.
18-Layer Rigid-Flex PCB refers to a printed circuit board containing one or more rigid areas and one or more flexible areas, which is composed of rigid boards and flexible boards orderly laminated together, and is electrically connected with metallized holes. Rigid Flex PCB not only can provide the support function that rigid pcb should have, but also has the bending property of flexible board, which can meet the requirements of 3D assembly.
