TU-943R High-speed PCB - when wiring the multi-layer printed circuit board, as there are not many lines left in the signal line layer, adding more layers will cause waste, increase certain workload and increase the cost. To solve this contradiction, we can consider wiring on the electrical (ground) layer. First of all, the power layer should be considered, followed by the formation. Because it is better to preserve the integrity of the formation.
TU-883 PCB The branch length in high-speed TTL circuits should be less than 1.5 inches. This topology takes up less wiring space and can be terminated with a single resistor match. However, this wiring structure makes the signal reception at different signal receiving ends asynchronous. The following is about 6mm Thick TU883 High speed Backplane related, I hope to help you better understand 6mm Thick TU-883 PCB.
