Ladder PCB technology can reduce the thickness of PCB locally, so that the assembled devices can be embedded in the thinning area, and realize the bottom welding of ladder, so as to achieve the purpose of overall thinning.
Microstrip PCB refers to high-frequency PCB. For special circuit board with high electromagnetic frequency, generally speaking, high frequency board can be defined as frequency above 1GHz. The high frequency board comprises a core plate with a hollow groove and a copper clad plate bonded to the upper surface and the lower surface of the core board through flow glue. The edges of the upper opening and the lower opening of the hollow groove are provided with ribs.
Rt5880 PCB is made of high-end military material of Rogers 5000 system. It has very small dielectric and ultra-low loss, which makes the simulation effect of the product excellent.
High frequency step PCB With the small and diversified development of electronic products, restricted by the space and security, the traditional plane circuit board can not meet the requirements of many fields of electronic products, and more and more step PCB has been gradually developed.
In addition to the requirement for uniform thickness of the plating layer for drilling, backplane designers generally have different requirements for the uniformity of copper on the surface of the outer layer. Some designs etch few signal lines on the outer layer. The following is about Megtron6 step PCB related, I hope to help you better understand Megtron6 step PCB.
