RT6002 promotes continuous breakthroughs in reliability, efficiency and performance in the field of materials by providing advanced material technology, applied knowledge and global production and design collaboration.
The high-frequency control board is mainly composed of a high-frequency induction heating main control board and two drives. The high-frequency board technology uses SG3525A as a PWM pulse. The output pulse frequency range is 20KHZ-60KHZ, the pulse interval is 180 degrees, and the dead time You can adjust it yourself. The following is about Double sided RO4350B PCB related, I hope to help you better understand Double sided RO4350B PCB.
